High temperature dedusting power station pps filter bag

PPS is one of the most important high temperature thermoplastic polymers because it exhibits a number of desirable properties. These properties include resistance to heat, acids and alkalies, and to mildew, to bleaches, aging, and abrasion.

The acid and alkali resistance is Excellent. Meanwhile, PPS fiber does not burn, neither does it support burning. The temperature resistance is up to 200ºC (392ºF). The resistance to oxidation is poor. So the working environment requires the oxygen content less than 14%(Vol.), and the oxynitride content is less than 600mg/Nm3. The higher oxygen contents the lower working temperature.

Application:

electric station boiler, coal-fired boiler, waste incineration, metal smelting, chemical industry and low oxidation gas smoke. wood dust collector、woodworking dust collection、dust collector design、dust control systems、dust collector system、colector de polvo、dust extraction equipment、dust removal system

Surface Treatment:

1. Water and oil repellent treatment: A substantial increase in performance of water and oil repellent 2. Acrylic coating: A substantial increase in Abrasion resistance property 3. Carbon coating: Anti-spark 4. PTFE film: Improve filtration precision: ≤5gsm/Nm3, but lower the filtration efficiency; and a substantial increase in acid-base resistance property 5. PTFE paint-coating: Improve filtration precision: ≤10gsm/Nm3, does not lower the filtration efficiency; and a substantial increase in acid-base resistance property 6. PTFE dipping: Improve filtration precision: ≤25gsm/Nm3, does not lower the filtration efficiency; and a small increase in acid-base resistance property

Specifications

Name	PPS/polyphenylene sulfite fibre
Componet	Shell Fiber	PPS+PTFE
	Scrim	PTFE
Weight	400-650g/m2(Customized)
Air Permeability	120
Tensile Strength	Length	≥850
	Cross	≥1200
Elongation at break	Length	≤10
	Cross	≤40
Temperature	Continue	170℃
	Peaks	200℃
Characteristics	Good at corrosion resistance and slow decay,longivity in use
Finish	Heat Stabilization,Glaze,Singe,PTFE Impregnate
Use Scope	Unit with ESP and bags or old unit retrofits,or unit requires long longivity and lower oxygen.ESP for the dust contents with high SO2 and NOX.
